Season:2023
Brand:Mondraker
Code:010.230CDC
Frame
Chrono 29 Stealth Alloy, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle
Sizes
S: 395mm / M: 430mm / L: 470mm / XL: 520mm
Fork
RockShox Judy Silver TK 29, 120mm, TurnKey, Solo Air, tapered steerer tube, 15x110mm axle, 30mm steel stanchions, 51mm offset. Settings: Poplock 2 pos remote compression (open/lock), rebound, air preload
Fork remote
RockShox PopLoc
Headset
ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem
ONOFF Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S/M: 50mm, size L: 60mm, size XL: 70mm
Handlebar
ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore
Grips
ONOFF Twin, 1lock-on, 135mm
Seatpost
ONOFF Pija dropper internal, diameter 31.6mm, S/M size: 405x95-125mm, L/XL size 458x120-150mm
Saddle
Mondraker XC Series, steel rail
Front brake
Sram Level, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Level, tooled reach adjust, lever pivot bushings
Rims
MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Front hub
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
Rear hub
Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts
Front tire
Maxxis Ardent 29x2.40, 60TPI, folding bead
Rear tire
Crankset
Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
Rings
34T, steel, X-Sync 2
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram SX Eagle, 12s, Powerlock
Rear derrailleur
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Casette
Sram PG-1210, 11-50T, 12s
Derailleur hanger
Mondraker M068
Weight
13,8 kg
